Laboratory bacterial incubator;Constant temperature incubator
Name：Electric heating incubator(Gated)
Model：DH-360/360B
Subdivide：
Details
Parameter
Features
Question
Product description
The gated incubator is suitable for the cultivation experiments of bacteria/microorganisms in industrial and mining enterprises, food processing, agriculture, biochemistry, biology and pharmaceutical industries.
Features
The DH series electric heating constant temperature incubator is composed of a box body and a temperature control system. The box body is made of high-quality cold-rolled steel plate, with spray-coated surface. The inner tank is made of high-quality steel plate or stainless steel plate for user's choice. The inner door is made of tempered glass, which makes it easy to observe the experimental state at any time. Use high quality insulation material for the inner liner and outer casing. The box is equipped with high-precision digital display instrument and power switch. The pull-out baffle is convenient for sampling.
The temperature control system adopts a microcomputer chip processor and a digital display instrument with functions such as PID adjustment characteristics, time setting, temperature difference correction, high temperature alarm, etc. It has high precision temperature control and strong function. The professionally designed studio air circulation system allows the heat generated by the bottom heater to enter the working chamber in a natural convection manner, thereby increasing the uniformity of temperature in the working chamber.
The main technical parameters:
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H360mm
Outer size : W480*D490*H610mm
Package size: W620*D600*H840mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5~65℃
Temperature fluctuation :±1℃
N.W: 50kg; G.W: 63kg
The gated incubator is suitable for the cultivation experiments of bacteria/microorganisms in industrial and mining enterprises, food processing, agriculture, biochemistry, biology and pharmaceutical industries.
Features
The DH series electric heating constant temperature incubator is composed of a box body and a temperature control system. The box body is made of high-quality cold-rolled steel plate, with spray-coated surface. The inner tank is made of high-quality steel plate or stainless steel plate for user's choice. The inner door is made of tempered glass, which makes it easy to observe the experimental state at any time. Use high quality insulation material for the inner liner and outer casing. The box is equipped with high-precision digital display instrument and power switch. The pull-out baffle is convenient for sampling.
The temperature control system adopts a microcomputer chip processor and a digital display instrument with functions such as PID adjustment characteristics, time setting, temperature difference correction, high temperature alarm, etc. It has high precision temperature control and strong function. The professionally designed studio air circulation system allows the heat generated by the bottom heater to enter the working chamber in a natural convection manner, thereby increasing the uniformity of temperature in the working chamber.
The main technical parameters:
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H360mm
Outer size : W480*D490*H610mm
Package size: W620*D600*H840mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5~65℃
Temperature fluctuation :±1℃
N.W: 50kg; G.W: 63kg
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H360mm
Outer size : W480*D490*H610mm
Package size: W620*D600*H840mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5-65℃
Temperature fluctuation :±1℃
N.W: 50kg; G.W: 63kg
Inner size : W360*D360*H360mm
Outer size : W480*D490*H610mm
Package size: W620*D600*H840mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5-65℃
Temperature fluctuation :±1℃
N.W: 50kg; G.W: 63kg
| Model | DH-360/360B | DH-400/400B | |
| Application | Laboratory bacterial incubator | ||
| Air circulation type | Natural convection | ||
| Performance | Operating temperature range | RT+5~65℃ | |
| Temperature resolution | 0.1℃ | ||
| Temperature fluctuation | ±0.5℃ | ||
| Temperature uniformity | ±1.0℃ | ||
| Structure | Liner material |
Note: After the model number, B indicates that the internal material is stainless steel, and no B indicates that the internal material is steel. |
|
| Shell material |
cold-rolled steel plate electrostatic spraying |
||
| Insulation materials | Polyurethane | ||
| Heating element | Alloy wire | ||
| Rated power | 0.3Kw | 0.4Kw | |
| Vent | Inner diameter 40mm, top ventilation | ||
| Controller | Temperature control | LCD,PID | |
| Temperature setting | Tap the four button to set | ||
| Temperature display | Actual temperature digital display (line 1); set temperature digital display (line 2) | ||
| Timing | 0~9999 minutes (with timing function) | ||
|
Running function |
Timed running, fixed value running, automatic stop | ||
| Additional features | Deviation correction, menu button lock, power failure compensation, power failure memory | ||
| Sensor | Cu50 | ||
| Safety equipment |
Over temperature alarm, water level alarm |
||
| Specification | Inner size(W*D*H mm) | 360*360*360 | 400*400*450 |
| Outer size(W*D*H mm) | 480*490*610 | 520*530*700 | |
| Package size(W*D*H mm) | 620*600*840 | 690*650*950 | |
| Capacity | 45L | 72L | |
| Partition load bearing | 15Kg | ||
| Maximum number of partitions | 8 layers | 11 layers | |
| Voltage (50/60Hz) / rated current | AC220V/1.4A | AC220V/1.8A | |
| N.W/G.W | 50/63Kg | 65/78kg | |
| Accessory |
Partition |
2 layers | |
| Optional device |
Separator, RS485 interface, printer, recorder, external communication, remote control, program temperature controller, wireless SMS alarm, U disk data storage |
||
|
Product page link |
Details | Details | |
|
Model |
DH-360/360B |
DH-400/400B |
|
Air circulation type |
Natural convection |
|
|
Inner size(W*D*H mm) |
360*360*360 |
400*400*450 |
|
Outer size(W*D*H mm) |
480*490*610 |
520*530*700 |
|
Rated power |
0.3kw |
0.4kw |
|
Capacity |
45L |
72L |
|
N.W./G.W. |
50/63kg |
65/78kg |
|
Liner material |
DH：Cold rolled steel; B: Stainless steel |
|
|
Shell material |
cold-rolled steel plate electrostatic spraying |
|
|
Operating temperature range |
RT+5~65℃ |
|
|
Temperature fluctuation |
±0.5℃ |
|
|
Timing |
0~9999 minutes (with timing function) |
|
|
Power supply |
AC220V 50/60HZ |
|
1. Can you customize the product?
Yes, we can customize any products according to customer’s requirements.
2. Which payment terms are you doing?
T/T (Bank telegraphic transfer,100% payment in advance.).
PayPal (Paypal only pay less than $500, and must be transported by Express.).
West Union.
3. Which shipment is available?
Sea freight, air transport, rail transport, international express or as your requirements.
4. Which country you have been exported?
Our products have been exported to many countries, more than 100 countries and regions around the world.
5. How long is the delivery time?
It’s about 7-20 days.
6、What trade methods do you offer?
The trade methods we support are FOB, FCA, CIF,EXW,DDU.
Yes, we can customize any products according to customer’s requirements.
2. Which payment terms are you doing?
T/T (Bank telegraphic transfer,100% payment in advance.).
PayPal (Paypal only pay less than $500, and must be transported by Express.).
West Union.
3. Which shipment is available?
Sea freight, air transport, rail transport, international express or as your requirements.
4. Which country you have been exported?
Our products have been exported to many countries, more than 100 countries and regions around the world.
5. How long is the delivery time?
It’s about 7-20 days.
6、What trade methods do you offer?
The trade methods we support are FOB, FCA, CIF,EXW,DDU.
