Product description
The gated incubator is suitable for the cultivation experiments of bacteria/microorganisms in industrial and mining enterprises, food processing, agriculture, biochemistry, biology and pharmaceutical industries.
Features
The DH series electric heating constant temperature incubator is composed of a box body and a temperature control system. The box body is made of high-quality cold-rolled steel plate, with spray-coated surface. The inner tank is made of high-quality steel plate or stainless steel plate for user's choice. The inner door is made of tempered glass, which makes it easy to observe the experimental state at any time. Use
high quality insulation material for the inner liner and outer casing. The box is equipped with high-precision digital display instrument and power switch. The pull-out baffle is convenient for sampling.
The temperature control system adopts a microcomputer chip processor and a digital display instrument with functions such as PID adjustment characteristics, time setting, temperature difference correction, high temperature alarm, etc. It has high precision temperature control and strong function. The professionally designed studio air circulation system allows the heat generated by the bottom heater to enter the working chamber in a natural convection manner, thereby increasing the uniformity of temperature in the working chamber.
The main technical parameters:
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H360mm
Outer size : W480*D490*H610mm
Package size: W620*D600*H840mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5~65℃
Temperature fluctuation :±1℃
N.W: 50kg; G.W: 63kg
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H360mm
Outer size : W480*D490*H610mm
Package size: W620*D600*H840mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5-65℃
Temperature fluctuation :±1℃
N.W: 50kg; G.W: 63kg
| Model | DH-360/360B | DH-400/400B |
| Application | Laboratory bacterial incubator |
| Air circulation type | Natural convection |
| Performance | Operating temperature range | RT+5~65℃ |
| Temperature resolution | 0.1℃ |
| Temperature fluctuation | ±0.5℃ |
| Temperature uniformity | ±1.0℃ |
| Structure | Liner material | Note: After the model number, B indicates that the internal material is stainless steel,
and no B indicates that the internal material is steel. |
| Shell material | cold-rolled steel plate electrostatic spraying
|
| Insulation materials | Polyurethane |
| Heating element | Alloy wire |
| Rated power | 0.3Kw | 0.4Kw |
| Vent | Inner diameter 40mm, top ventilation |
| Controller | Temperature control | LCD,PID |
| Temperature setting | Tap the four button to set |
| Temperature display | Actual temperature digital display (line 1); set temperature digital display (line 2) |
| Timing | 0~9999 minutes (with timing function) |
Running function
| Timed running, fixed value running, automatic stop |
| Additional features | Deviation correction, menu button lock, power failure compensation, power failure memory |
| Sensor | Cu50 |
| Safety equipment | Over temperature alarm, water level alarm
|
| Specification | Inner size(W*D*H mm) | 360*360*360 | 400*400*450 |
| Outer size(W*D*H mm) | 480*490*610 | 520*530*700 |
| Package size(W*D*H mm) | 620*600*840 | 690*650*950 |
| Capacity | 45L | 72L |
| Partition load bearing | 15Kg |
| Maximum number of partitions | 8 layers | 11 layers |
| Voltage (50/60Hz) / rated current | AC220V/1.4A | AC220V/1.8A |
| N.W/G.W | 50/63Kg | 65/78kg |
| Accessory | Partition
| 2 layers |
| Optional device | Separator, RS485 interface, printer, recorder, external communication, remote control,
program temperature controller, wireless SMS alarm, U disk data storage |
Product page link
| Details | Details |
| Model | DH-360/360B | DH-400/400B |
Internal dimensions (W*D*H mm) | 360*360*360 | 400*400*450 |
External dimensions (W*D*H mm) | 480*490*610 | 520*530*700 |
| Rated power | 0.3KW | 0.4KW |
| Capacity | 45L | 72L |
| N.W./G.W. | 50/63kg | 65/78kg |
| Air circulation type | Natural convection |
| Liner material | DH：Cold rolled steel; B: Stainless steel |
| Shell material | cold-rolled steel plate electrostatic spraying |
| Operating temperature range | RT+5~65℃ |
| Temperature fluctuation | ±0.5℃ |
| Timing | 0~9999 minutes (with timing function) |
| Power supply | AC220V 50/60HZ |
1. Can products be customized?
Yes, fully customizable per your specifications.
2. Accepted payment terms?
T/T (100% advance bank transfer) - SWIFT, FAST, MEPS, GIRO, and ACH accepted
PayPal (Amount less than $500, and must be transported by Express.).
Credit Card
Letter of Credit (LC)
3. Available shipping methods?
By Sea, By air, rail transport, international express or as per your request.
4. Export experience?
We export globally, serving clients in over 100 countries and regions.
5. How long is the production time?
Standard product: 5-10 days, customized product: 15-30 days.
6、Supported trade terms?
FOB, CIF, EXW, FCA, DDU, DAP and DDP.
Ejer Tech.(China) is a technology-driven enterprise, engaged in the R&D, production and sales of the dry cabinets, precision laboratory equipment and other electric equipment. The headquarters is in Hangzhou, sits adjacent to Alibaba's global headquarters. There are branches all over the country. Our products have been sold to more than 100 countries and regions. Our main products are widely used in the fields of electronics industries, research institutions, government agencies, chemical industries, pharmaceutical industries and etc. The quality of our products is stable and reliable, thus are trusted by the customers worldwide.
